Sensotec's
Torque Sensors feature both Reaction (non-rotation) and
Rotary Torque Sensors that utilize Bonded Strain gauge
Technology. The New Rotary Torque capability offers both
in-line mounting configurations and clamp-on sensors that
cover the ranges of +/- 100 inch pounds to 24,000 inch
pounds, and shaft diameters from 3.5 inches up to 32 inches.
These Rotary Torque Sensors are capable of sensing torque
over rotational speeds from zero rpm to 15,000 rpm. The
Sensotec Rotary Torque Sensors are non-contact and do not
use support bearings or slip rings. The torque signal from
the strain gauge sensors is rf coupled to a loop antenna. An
rf receiver converts the signal to 0 +/- 5vdc output.
The Reaction
Torque Sensors offer torque measurements from 10 ounce inch
to ranges of 3 Million pound inch. A vareity of mounting
configurations are offered including: Shaft to Shaft, Flange
to Flange, and Shaft to Flange on the low range models. All
of Sensotecs Torque Sensors are machined from stainless
steel and temperature hardened for low torsional deflection
as well as temperature compensated for long-term stability.
Applications include automotive braking, engine and
transmission dynamometers, torque table, fastener testing,
aircraft engine testing, and marine shaft torque
measurements with shaft horsepower monitors.
|
