High-accuracy features and a unique modular design make the APC4000 automatic pressure controller ideal for quick and accurate calibration testing and cycling of pressure sensitive devices.

The APC4000 automatically measures or controls pressure up to 10,000 psi. Featuring eight independent ranges, this fast response system secures accurate readings within 0.05%. Precision stepper motor provides the ultimate in control, eliminating overshoot and human error.

The APC4000 incorporates a unique modular design. By introducing additional UPS3000 units, expansion is obtained at a fraction of the price a new controller would cost. This versatile unit also includes four standard menu prompted modes, and offers the choice of manual or computer operation.

From aerospace to computers, health care to pharmaceutical, the APC4000 is the ultimate solution for automatic pressure control in a variety of industries.

應用領域:

• Pressure transducer manufacturing

• Pressure transmitter multi-unit automated testing

• Pressure cycling for QA acceptance

產品特色:

• Available in eight ranges: 10,000/5000/2000 psi, 5000/2500/1000 psi, 2000/1000/400 psi, 1000/500/200 psi, 500/250/100 psi, 100/50/20 psi, 50/25/10 psi, and 15/7.5/3 psig

• Automatically measure or control pressure up to 10,000 psi, absolute or gage calibration

• Fast response

• ±0.05% F.S. accuracy for each range

• Standard menu prompted modes include: manual calibration test sequence, automatic calibration test sequence, manual operation, automatic pressure cycling

• Operate manually, or by computer via RS-422 or IEEE 488 interface

• Precision stepper motor control to eliminate overshoot

• Expandable—Additional UPS 3000 units provide more pressure ranges at a fraction of the cost

• Stress cycle mode to exercise any pressure sensitive device

• Ideal for taking the human error out of routine calibrations

• Interface ports link the APC4000 to personal computers, mainframes, printers, and data acquisition systems to enhance data analysis, data recording, and remote control for factory automation

• Multi-engineering units standard: psi, kPa, mmHg, BAR, mBAR, in Hg, cmH2O, inH2O, kg/cm2, % F.S.

• Self-contained rack mount version available

Options/Accessories:

• AutoCAL 4000™ software package with LABVIEW drivers (LABVIEW is a trademark of National Instruments)

• TMU295 ticket printer

• TM-300 tape printer

• 25-pin interface cable

【型錄下載】Download Catalog/Specs PDF files

Rugged, versatile, portable...the UVC1000 vacuum generator/pressure controller packs a lot of performance into one affordable instrument.

Complete mechanical operation allows operators to utilize the UVC1000 in areas that are off limits to vacuum pumps. This efficient unit contains a built-in vacuum converter that works with existing shop air to power up to 29 inches of Hg vacuum. As a result, the UVC1000 eliminates fumes and vibrations that are dangerous in nuclear power plants, oil refineries, and other hazardous environments.

Regardless of the location, the UVC1000 is convenient for on-the-go operation. Its lightweight structure and compact design provide quick and convenient performance. This versatile unit can also be used to control and regulate positive pressure.

The UVC1000...the ideal source for vacuum and pressure control in an endless number of applications and locations.

應用領域:

• Hazardous environments

• Source for calibration of compound gages

• Low-cost alternative to vacuum pump

• Need for precise vacuum or pressure control

產品特色:

• Two modes of operation: vacuum or pressure

• 29" Hg vacuum from shop air supply

• Lightweight design

• Built-in vacuum converter and pressure regulator

• Available as standard (UVC1000) or rack mounted version (UVC1010)

【型錄下載】Download Catalog/Specs PDF files
