可攜式壓力校正儀

DPI 320/325 【可攜式高壓氣體校正器】

Portable High Pressure Pneumatic Calibrators

• High accuracy 0.025% FS

• Generates pneumatic pressures to 200 bar

• Dual channel readout: pressure and electrical

• Self contained rechargeable gas cylinder

• RS 232 interface and documenting versions

• Up to 11 sensors per instrument

【型錄下載】Download Data Sheet

DPI 330/335 【可攜式高壓液體校正器】

Portable High Pressure Hydraulic Calibrators

• High accuracy 0.025% FS

• Generates pressures up to 10,000 psi

• Dual pressure and electrical readout

• Thermal compensator for high speed stable control

• Unique vacuum priming of hydraulic system

• RS 232 interface and documenting versions

【型錄下載】Download Data Sheet

DPI 610/615 【可攜式壓力校正器】

Portable Pressure Indicator/Calibrator

• Ranges from 0 to 2.5 mbar through to 700 bar

• Accuracy 0.025% FS all ranges

• Integral combined pressure/vacuum pump

• Dual readout

• 4 to 20mA loop test facility

• Intrinsically safe (IS) version

• RS232 interface and fully documenting version

• Pressure / vacuum pump

• Remote pressure sensors

【型錄下載】Download Data Sheet

PV 411 【多功能壓力泵】

Multi-function Pressure Generator

• Multi-function 4 in 1 handpump

• 60 bar pneumatic, 700 bar hydraulic

• Generates vacuum to 95%

• Vacuum priming for hydraulic systems

• Excellent low pressure control

• Adjustable overpressure protection

【型錄下載】Download Data Sheet

DPI 104 【數位式壓力表】

Digital Test Gauge

• 0.05% full scale (FS) accuracy

• Pressure ranges to 20,000 psi (1400 bar)

• Eleven selectable pressure units

• Large, easy to read display with five digit resolution

• % pressure indication and additional bar graph for quick visual reference

• Temperature compensated accuracy from 14蚌 to 122蚌 (-10蚓 to 50蚓)

• 0 to 5V analogue output

• Pressure switch test

• Minimum/Maximum, tare and alarm functions

• IDOS compatible and RS232 serial interface

• Networking capability (1 to 99 units)

• Stainless steel or Inconel pressure cavity for aggressive media

• Networking capability (1 to 99 units)

• Stainless steel or Inconel pressure cavity for aggressive media

【型錄下載】Download Data Sheet

DPI 705 【手持式壓力指示器】

Handheld Digital Pressure Indicator

• Ranges from 0 to 70 mbar to 700 bar

• 0.1% FS accuracy

• Rugged, lightweight handheld design

• Lead test, tare, max/min and filter

• Intrinsically safe version

• Pneumatic and hydraulic test kits

• Standard ranges available ex-stock

【型錄下載】Download Data Sheet

DPI 800/802 【壓力指示器/校正器】

Pressure Indicator / Pressure Loop Calibrator

• Ranges from 25 mbar to 700 bar

• Single or dual range configuration

• Pressure test and maintenance

• Transmitter calibration

• Loop set-up and diagnostics

• Switch verification

• HART Resistor can be switched into the loop when required by a HART digital communicator.

• IDOS Flexibility (Intelligent Digital Output Sensor)

• Plug and Play

• Advanced Features: hold, maximum/minimum/average, alarm and tare facilitate troubleshooting

DPI 800 Pressure Indicator- the ideal tool for pressure test and measurement.

DPI 802 Pressure Loop Calibrator- provides simultaneous pressure and mA measurement for transmitter and loop maintenance.

【型錄下載】Download Data Sheet

DBC 150/160 【溫度校正器】

Dry Block Temperature Calibrators

• Ranges from -45� to 650慢

• Rapid heating, cooling and settling

• Switch test, ramp, step and preset functions

• Reads set temperature and device output simultaneously

• Measures reference probe, RTD's, T/C's mA, mV and ohms

• Automated calibration via RS 232

【型錄下載】Download Data Sheet
